Introduction
The Fiber Optic Experimental kit is a sister kit to EWGX-7. It provides additional experimental education to meet the requirement of rapid changing fiber communication field.
Experiment Examples
- Fiber optic isolator and parameter measurement
- Optical fiber beam splitter parameter measurement
- M-Z optical fiber interference experiment
- Optical fiber thermal sensing principle
- Optical fiber pressure sensing principle
- Experiment of fundamental knowledge of optical fiber optics
- Experiment of coupling method between optical fiber and light source
- Multimode fiber numerical aperture (NA) measurement
- Optical fiber transmission loss property and measurement
- Adjustable optical attenuator and parameter measurement
Components List
| Category
| Item #
| Description
| Model
| Qty.
|
| Light Source |
1 |
He-Ne Laser (1.5mw) |
GY-10 |
1 set |
| 2 |
Laser Diode |
1310 nm |
1 set |
| Receiver |
3 |
Laser Power Meter |
SGN-1 |
1 |
| 4 |
Handheld Laser Power Meter |
|
1 |
| Component |
5 Fiber
Interference
Demonstration
System |
Fiber Splitter |
633 nm |
1 |
| Temperature Control Unit |
|
1 |
| Pressure Control Unit |
|
1 |
| 5-Axis Adjustable Holder |
|
1 |
| Beam Expander |
t=4.5 mm |
1 |
| Fiber Holder |
|
2 |
| Fiber Supporter |
|
1 |
| White Screen w/cross pattern |
SZ-13C |
1 |
| Laser Holder |
SZ-42 |
1 |
| Target |
|
1 |
| Power Line |
|
1 |
| 6 |
Single Mode Beam Splitter |
1310nm |
1 |
| 7 |
Optical Isolator |
1310nm |
1 |
| 8 |
Adjustable Optical Attenuator |
|
1 |
| 9 |
Single Mode Fiber |
633nm |
2m |
| 9 |
Single Mode Fiber |
633nm (Fc/Pc) |
2m |
| 10 |
Multi Mode Fiber |
633nm |
2m |
| 11 |
Communication Optical Fiber |
1km |
1 |
| 12 |
Fiber Jumper |
1m/3m |
4/1 |
| 13 |
Fiber Striper |
|
1 |
| 14 |
Fiber Clever |
|
1 |
| 15 |
Fiber Clever |
|
1 |
| 16 |
Flange |
|
5 |
| 17 |
Tape Ruler |
2m |
1 |
|
|
